MTL4511 MTL Instruments Switch/Proximity Detector Interface 1-channel, with line fault detection

Achievers Automation Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

MTL4511 MTL Instruments Switch/Proximity Detector Interface 1-channel, with line fault detection

  • 1
  • 2
  • 3

Brand Name : MTL

Model Number : MTL4511

Certification : HART

Place of Origin : UK/China

MOQ : 1

Price : USD45.00/EA

Payment Terms : T/T, Alipay, Paypal

Supply Ability : 1000pcs per week

Delivery Time : stock

Packaging Details : carton

Manufacturer : MTL Instruments

Product no : MTL4511

Number of channels : One

Response time : 10ms maximum

Maximum current consumption : 25mA at 24V

Power dissipation within unit : 0.6W at 24V

Voltage applied to sensor : 7 to 9V dc from 1kΩ ±10%

Condition : Brand New

Contact Now

Product Introduction:
The MTLx511 enables a safe-area load to be controlled by a switch or proximity detector located in a hazardous-area. When selected, open
or short circuit conditions in the field wiring are detected by the line-fault-detect (LFD) facility and also indicated on the top of the module. Phase reversal for the channel is selected by a switch on the side of the module and output is provided by changeover relay contacts
Product Details:


  • Manufacturer: MTL Instruments

  • Product no : MTL4511

  • Product type : Switch/Proximity Detector Interface 1-channel, with line fault detection

  • Response time: 10ms maximum

  • Contact rating(Safe Area):10W, 0.5A,35V dc

  • Contact rating(Zone 2):10W, 0.5A,35V dc

  • Number of channels : One

  • Location of switches : Zone 0, IIC, T6 hazardous area,Div. 1, Group A hazardous location

  • Location of proximity detector : Zone 0, IIC, T4–6 hazardous area if suitably certified, Div. 1, Group A hazardous location

  • Hazardous-area inputs : Inputs conforming to BS EN60947–5–6:2001 standards for proximity detectors (NAMUR)

  • Voltage applied to sensor : 7 to 9V dc from 1kO ±10%

  • Input/output characteristics : Normal phase, Outputs closed if input > 2.1mA (< 2kO in input circuit), Outputs open if input < 1.2mA (> 10kO in input circuit), Hysteresis: 200µA (650O) nominal

  • Shipping Weight : 1 Kg
