Pepperl Fuchs Inductive sensor NBN30-U4-A2
| General specifications |
|---|
| Switching function | complementary |
| Output type | PNP |
| Rated operating distance | 30 mm |
| Installation | non-flush |
| Output polarity | DC |
| Assured operating distance | 0 ... 24.3 mm |
| Reduction factor rAl | 0.33 |
| Reduction factor rCu | 0.31 |
| Reduction factor r304 | 0.74 |
| Reduction factor rBrass | 0.38 |
| Output type | 4-wire |
| Nominal ratings |
|---|
| Operating voltage | 10 ... 30 V |
| Switching frequency | 0 ... 230 Hz |
| Hysteresis | typ. 5 % |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Voltage drop | ≤ 2 V |
| Operating current | 0 ... 200 mA |
| Off-state current | 0 ... 0.5 mA |
| No-load supply current | ≤ 20 mA |
| Time delay before availability | 80 ms |
| Operating voltage indicator | LED, green |
| Switching state indicator | LED, yellow |
| Functional safety related parameters |
|---|
| MTTFd | 1230 a |
| Mission Time (TM) | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Compliance with standards and directives |
|---|
| Standard conformity |
|
| Standards | EN IEC 60947-5-2 |
| Approvals and certificates |
|---|
| UL approval | cULus Listed, General Purpose |
| CCC approval | CCC approval / marking not required for products rated ≤36 V |
| Ambient conditions |
|---|
| Ambient temperature | -25 ... 85 °C (-13 ... 185 °F) |
| Mechanical specifications |
|---|
| Connection type | screw terminals |
| Core cross section | max. 2.5 mm2 |
| Housing material | PA/metal with epoxy powder coating |
| Sensing face | PA |
| Housing base | metal |
| Degree of protection | IP68 / IP69K |
| Mass | 225 g |
| Dimensions |
|
| Height | 40 mm |
| Width | 40 mm |
| Length | 118 mm |
| Note | Tightening torque: 1.8 Nm (housing) |
